Flat Ribbon Cable

We Custom Supply Shielded Flat Ribbon cable and Jacketed flat ribbon cable for medical cable assemblies.
The flat ribbon cable types from 2 pins(core) to,3 pin,4pin,15 pin,24pin …and 40 pin.Flat extension cord.

Application range from medical accessories and eletronics.such as Medical cable assembly (Holter ECG recorder cable,EEG,EMG…),and Flat USB cable and rj45 flat extension cord.Among medical ribbon cables,Flat ECG cable are Shielded ribbon cable with separate shield for each wire. In most cases,Flat Ribbon cable are very simple even without an extra Jacket.

Colors,Jacket material,Diameters and Condutor material/ squaremeters can customize according to your requirement.

There are two main types of Flat ribbon cable in terms of its producing method:
1) one-step Jacket Extruding,in this situation,the Jacket can be only one color ,as you can find on this page,such as EC205S-002. the colors can maximum be 2 colors

2) Sticking different colors wires together. This is usually called ” Rainbow ribbon cable”.it uses heat-shrinkable mylar to finish the processing.there is no limit to the colors you want. its cost is much higher.

If you have not found a matchable ribbon cable from our existing stock,please tell us what specification flat ribbon cable you need:

4 core flat cable 20 AWG High Voltage Wire 26 AWG Signal wire PVC Jacket

4 core flat cable 20 AWG High Voltage Wire 26 AWG Signal

4 core flat cable 20 AWG High Voltage Wire 26 AWG Signal Wire This 4 core flat cable composes of 20 AWG for High Voltage and 2 wire 26 AWG for Signal;the 20 awg wire …

Read More4 core flat cable 20 AWG High Voltage Wire 26 AWG Signal wire PVC Jacket

23 AWG 2 core flat cable Low noise with Tinsel Conductor

23 AWG 2 core flat cable Low noise with Tinsel Conductor

23 AWG 2 core flat cable Low noise with Tinsel Conductor This 2 core flat cable is intended for 2 lead ecg cable assembly,and it adopts Tinned Tinsel,So this 23 AWG cable is in terms …

Read More23 AWG 2 core flat cable Low noise with Tinsel Conductor

29 AWG 2 Core Flat cable 1P+3C Braid Shield TPU Jacket

29 AWG 2 Core Flat Cable 1P+3C Braid Shield TPU Jacket

29 AWG 2 Core Flat Cable 1P+3C Braid Shield This 2 Core Flat cable is based on Tinned Copper Alloy Conductor ,with Braid Shield TPU Jacket.One Core includes a 29 AWG Pair,and another Core is …

Read More29 AWG 2 Core Flat cable 1P+3C Braid Shield TPU Jacket

Flat ribbon 13 core cable shielded for 13 lead ECG cable EC213S

Flat 13 core cable for 13 lead ECG

Flat 13 Core Cable Shielded for 13 Lead ECG-EC213S This Flat 13 Core Cable Shielded is intended for 13 Lead ECG Cable.13 leads ECG monitor cable can be done by a 11 lead Round cable …

Read MoreFlat ribbon 13 core cable shielded for 13 lead ECG cable EC213S

Round 3 lead ecg cable with special structure and better noise performance

3 lead ECG cable with Special structure

Round 3 Lead Ecg Cable With Special Structure EC203B This 3 lead ecg cable has the following structure advantages to assure its performance perfectly meet EC 53 standard,specially the requirement for low noise 1)There is …

Read MoreRound 3 lead ecg cable with special structure and better noise performance

Shielded Ribbon cable-2 leads ECG cable

2 leads ECG cable Shielded ribbon cable style

Shielded Ribbon Cable-2 Leads ECG Cable EC202S 2 leads ECG cable Shielded ribbon cable style EC202S 2 lead ecg cable cutting diagram technical specification Items  Specification Products name Shield Ribbon Cable for ECG Model EC202S …

Read MoreShielded Ribbon cable-2 leads ECG cable

Shielded Ribbon cable-3 leads Flat cable for ECG leads

ECG cable EC203S

Shielded Ribbon Cable-3 Leads Flat Cable For ECG Leads 3 leads Shileded Ribbon cable technical specification Items  Specification Products name Shield Ribbon Cable for ECG Model EC203S Conductor  Material Tinned or Silvered Tinsel+KEVLAR  Specification 7/0.23+200D …

Read MoreShielded Ribbon cable-3 leads Flat cable for ECG leads

Colorful 13 Flat Ribbon Cable -OE113X

13 Flat Ribbon cable unshielded medical cable-OE113X technical specification 2.AWG&Matreial Component Component 1 Conductor Material BARE COPPER AWG 25 Construction 19/0.10 (Pitch)mm 6±2 (Pitch Direction) Left (Stranded O.D)mm 0.45 Jacket Material PVC (O.D) mm 1.23+0/-0.02*13F …

Read MoreColorful 13 Flat Ribbon Cable -OE113X

8 colors Flat Ribbon Cable unshielded -OE108X

8 Flat Ribbon cable

8 Flat Ribbon cable unshielded medical cable-OE108X technical specification 2.AWG&Matreial Component Component 1 Conductor Material BARE COPPER AWG 25 Construction 19/0.10 (Pitch)mm 6±2 (Pitch Direction) Left (Stranded O.D)mm 0.45 Jacket Material PVC (O.D) mm 1.23+0/-0.02*8F …

Read More8 colors Flat Ribbon Cable unshielded -OE108X

1P+4C Flat shielded SPO2 sensor Cable SP206S-003

1P+4C Flat Shielded SPO2 Sensor Cable SP206S-003 Spo2 cable technical specification Items  Specification Products name   Model SP206S-003 Conductor  Material Tinned copper Tinned copper  Specification 25/0.O5TC士0. 008 25/0.O5TC士0.008 Insulation  Material HDPE HDPE  Nom.Thickness 0.12 0.12 …

Read More1P+4C Flat shielded SPO2 sensor Cable SP206S-003

Post navigation
Older posts
1 2 3 Next →
